USED SUPERGRAIN L3-3D CROSS GRAIN MOULDER

USED SUPERGRAIN L3-3D CROSS GRAIN MOULDER

Contact us for price

Burns, TN

orCall 615-441-3370

Description

Used, in excellent condition, L3-3D Cross Grain Moulder LHG Machine/LH Controls Infeed Conveyor with adjustable rollers and adjustable side guides Six roller sheeter head with UHMW-covered rollers 12" wide grooved top rollers, 15" wide middle and bottom rollers, gear driven Digital indicators show.... Used, in excellent condition, L3-3D Cross Grain Moulder LHG Machine/LH Controls Infeed Conveyor with adjustable rollers and adjustable side guides Six roller sheeter head with UHMW-covered rollers 12"-wide grooved top rollers, 15"-wide middle and bottom rollers, gear driven Digital indicators show roller spacing Scrapers are hardened, ground and teflon coated Special vari-flow dusters included for head, and moulding conveyor, 90 VDC 16"-wide transfer belt, pebble top, variable speed, 550FPM Max Teflon-coated slide plate with air jet 28"-wide endless moulding belt, variable speed 200' FPM Max Universal-style pressure board 27" x 60" powered with adjustable side guides, hinged with gas shock lift assist Sideways stretch conveyor with 3/4" high side guides, 1/2 HP drive Stainless steel dough discharge chute Heavy stainless steel base, reinforced stsainless steel moulding table All ball-bearings Mounted on adjustable height legs Gearhead motors:    230 volts, 3 phase, 60 hz    1-1/2 hp sheeter drive - constant speed    3/4 hp transfer conveyor drive - AC inverter    1/2 hp sideways conveyor drive - ac inverter    2 hp moulder conveyor drive - ac inverter    U.L. listed electrical panel 12"-wide grooved top rollers, 15"-wide middle and bottom rollers, gear driven Digital indicators show roller spacing Scrapers are hardened, ground and teflon coated Special vari-flow dusters included for head, and moulding conveyor, 90 VDC 16"-wide transfer belt, pebble top, variable speed, 550FPM Max Teflon-coated slide plate with air jet 28"-wide endless moulding belt, variable speed 200' FPM Max Universal-style pressure board 27" x 60" powered with adjustable side guides, hinged with gas shock lift assist Sideways stretch conveyor with 3/4" high side guides, 1/2 HP drive Stainless steel dough discharge chute Heavy stainless steel base, reinforced stsainless steel moulding table All ball-bearings Mounted on adjustable height legs Gearhead motors:   230 volts, 3 phase, 60 hz   1-1/2 hp sheeter drive - constant speed   3/4 hp transfer conveyor drive - AC inverter   1/2 hp sideways conveyor drive - ac inverter   2 hp moulder conveyor drive - ac inverter   U.L. listed electrical panel

Specifications

ConditionUsed
Stock NumberL3-3D-01
